Fluid energy mill is a high-efficiency pneumatic micronizer widely used in pharmaceutical particle size reduction. This introduction summarizes the fluid energy mill – principle, construction, working, uses, merits, demerits – in clear, exam-focused language for B.Pharm students. Understand jet collision and fluidization principles, key parts such as nozzle, grinding chamber and classifier, critical operating variables (air pressure, feed rate, residence time), material suitability, and common pharmaceutical applications like dry grinding of APIs and excipients. Coverage also includes comparison with other mills, maintenance essentials, contamination control and scale-up considerations to support both practical lab work and theoretical exams. Now let’s test your knowledge with 50 MCQs on this topic.
Q1. What is the primary principle by which a fluid energy mill reduces particle size?
- Mechanical impact from rotating hammers
- Compression against a fixed surface
- Particle–particle collisions driven by high velocity fluid jets
- Abrasive action of grinding media
Correct Answer: Particle–particle collisions driven by high velocity fluid jets
Q2. Which of the following is NOT a main component of a fluid energy mill?
- Nozzle or jet assembly
- Grinding media like steel balls
- Grinding chamber
- Classifier or collector
Correct Answer: Grinding media like steel balls
Q3. Which fluid is most commonly used as the milling medium in pharmaceutical fluid energy mills?
- High viscosity oil
- Compressed air
- Liquid nitrogen (always)
- Hydraulic fluid
Correct Answer: Compressed air
Q4. The product particle size in a fluid energy mill is mainly controlled by which factor?
- Nozzle diameter, gas pressure and classifier speed
- Color of feed material
- Type of grinding media
- Temperature of the laboratory only
Correct Answer: Nozzle diameter, gas pressure and classifier speed
Q5. Why are fluid energy mills preferred for contamination-sensitive APIs?
- They use inert ceramic grinding media
- They have no moving mechanical parts that contact the product
- They dissolve the API during milling
- They coat particles with polymer during milling
Correct Answer: They have no moving mechanical parts that contact the product
Q6. Which material property makes a substance ideal for milling in a fluid energy mill?
- High plasticity and ductility
- High hardness and brittleness
- Extremely elastic behavior
- Very sticky and hygroscopic nature
Correct Answer: High hardness and brittleness
Q7. What is the role of the classifier in a fluid energy mill?
- To add moisture to the product
- To separate fine particles from coarse and control product size
- To mechanically crush oversized particles
- To heat the product before packaging
Correct Answer: To separate fine particles from coarse and control product size
Q8. Which operational parameter increases the degree of micronization in a fluid energy mill?
- Decreasing gas pressure
- Increasing feed particle size without changing other parameters
- Increasing jet gas velocity (pressure)
- Reducing nozzle number
Correct Answer: Increasing jet gas velocity (pressure)
Q9. A common advantage of fluid energy mills over ball mills is:
- Lower energy consumption always
- Absence of grinding media minimizing contamination
- Ability to process highly plastic materials better
- They are cheaper for large scale only
Correct Answer: Absence of grinding media minimizing contamination
Q10. Which statement about temperature control in a fluid energy mill is true?
- Temperature never rises during milling
- Temperature can rise due to compression and collisions; cooling mediums or chilled air may be required
- Temperature is irrelevant for all APIs
- Temperature is controlled by adding solvents
Correct Answer: Temperature can rise due to compression and collisions; cooling mediums or chilled air may be required
Q11. What is a primary demerit of using fluid energy mills?
- They always cause chemical degradation
- Relatively high energy consumption for very fine particles
- They cannot produce submicron particles
- They require large volumes of solvents
Correct Answer: Relatively high energy consumption for very fine particles
Q12. Which product characteristic is typically improved after milling with a fluid energy mill?
- Bulk drug’s melting point
- Particle size distribution and specific surface area
- Chemical structure of API
- Total solid content
Correct Answer: Particle size distribution and specific surface area
Q13. In a jet mill, what is the usual effect of increasing feed rate while keeping gas pressure constant?
- Product becomes finer due to more collisions
- Product tends to coarsen because residence time decreases and overloading occurs
- It has no effect
- It always improves product purity
Correct Answer: Product tends to coarsen because residence time decreases and overloading occurs
Q14. Which type of nozzle arrangement is commonly used in fluid energy mills for higher intensity?
- Single static plate
- Counter-jet or multiple opposing nozzles
- Perforated rotating disk
- Fixed abrasive strip
Correct Answer: Counter-jet or multiple opposing nozzles
Q15. Which of the following is a common application of fluid energy mills in pharmacy?
- Wet granulation of tablets
- Dry micronization of active pharmaceutical ingredients (APIs)
- Sterile filtration of parenteral solutions
- Coating tablet cores
Correct Answer: Dry micronization of active pharmaceutical ingredients (APIs)
Q16. How does particle hardness influence milling in a fluid energy mill?
- Harder particles are harder to fracture, often requiring higher jet energy
- Hardness has no effect
- Softer particles always produce narrower PSD
- Hard particles dissolve during milling
Correct Answer: Harder particles are harder to fracture, often requiring higher jet energy
Q17. Which of the following milling media is NOT used in a fluid energy mill?
- Compressed air
- Steam
- Grinding beads
- Inert gases like nitrogen
Correct Answer: Grinding beads
Q18. What is the effect of moisture in feed material for a fluid energy mill?
- Moisture improves milling efficiency always
- High moisture leads to agglomeration and poor milling performance
- Moisture transforms the material chemically
- Moisture has no effect on milling
Correct Answer: High moisture leads to agglomeration and poor milling performance
Q19. Which safety consideration is important when using a fluid energy mill with fine pharmaceutical powders?
- Explosion risk due to dust and pressurized gas, requiring grounding and inerting when needed
- No safety measures are necessary
- Only radiation shielding is important
- Only cryogenic hazards are present
Correct Answer: Explosion risk due to dust and pressurized gas, requiring grounding and inerting when needed
Q20. How does a fluid energy mill differ from a ball mill?
- Fluid energy mill uses grinding media while ball mill does not
- Fluid energy mill uses high-velocity jets and particle–particle collisions; ball mill uses tumbling grinding media
- They are identical in principle
- Ball mills are always used for gaseous products only
Correct Answer: Fluid energy mill uses high-velocity jets and particle–particle collisions; ball mill uses tumbling grinding media
Q21. Which parameter is adjusted to narrow the particle size distribution in a fluid energy mill?
- Increase ambient humidity
- Optimize classifier setting and jet energy
- Eliminate the classifier entirely
- Reduce inlet air filtration
Correct Answer: Optimize classifier setting and jet energy
Q22. Which of the following feed preparations may improve performance in fluid energy milling?
- Agglomeration of feed into large lumps
- Drying and pre-crushing to a controlled size range
- Increasing oil content of feed
- Mixing feed with sticky binders
Correct Answer: Drying and pre-crushing to a controlled size range
Q23. In scale-up of a fluid energy mill process, which factor is most critical?
- Maintaining geometrically identical color schemes
- Reproducing energy density and jet velocities to match particle dynamics
- Using identical brand of compressed air
- Mimicking operator schedules exactly
Correct Answer: Reproducing energy density and jet velocities to match particle dynamics
Q24. For heat-sensitive APIs, which modification can make fluid energy milling safer?
- Use of chilled or cryogenic gases such as nitrogen or CO2
- Increasing gas temperature intentionally
- Adding water to the milling chamber
- Using metallic grinding media
Correct Answer: Use of chilled or cryogenic gases such as nitrogen or CO2
Q25. What is a common downstream step after fluid energy milling for pharmaceutical powders?
- Direct use without any handling
- Classification, sieving, and collection to ensure desired PSD and remove fines or oversize
- Immediate sterilization by heat
- Mixing with large amounts of solvent
Correct Answer: Classification, sieving, and collection to ensure desired PSD and remove fines or oversize
Q26. Which measurement best assesses the efficiency of micronization in a fluid energy mill?
- pH of the powder
- Particle size distribution metrics like D50 and D90
- Color index
- Viscosity of the powder
Correct Answer: Particle size distribution metrics like D50 and D90
Q27. Why can fluid energy mills be preferable for sterile pharmaceutical powders?
- They always sterilize the product during milling
- Absence of internal moving parts reduces hard-to-clean crevices and cross-contamination
- They produce large coarse particles ideal for sterile products
- They use disposable grinding beads
Correct Answer: Absence of internal moving parts reduces hard-to-clean crevices and cross-contamination
Q28. What happens if nozzle diameter is reduced while keeping pressure constant?
- Jet velocity decreases and milling reduces
- Jet velocity increases leading to higher energy density and potentially finer particles
- No change in milling
- The classifier will become redundant
Correct Answer: Jet velocity increases leading to higher energy density and potentially finer particles
Q29. Which of the following is a merit of fluid energy milling?
- High contamination from wear
- Capability to achieve very narrow submicron distributions with proper settings
- Low reproducibility
- Requires large quantities of solvents
Correct Answer: Capability to achieve very narrow submicron distributions with proper settings
Q30. In a fluid energy mill, what is the typical effect of increasing the classifier speed?
- Allows coarser particles to pass, making product coarser
- Rejects more coarse particles, producing finer product
- Has no influence on product size
- Always increases product contamination
Correct Answer: Rejects more coarse particles, producing finer product
Q31. The most suitable feed particle size range for efficient fluid energy milling is generally:
- Extremely coarse (>5 mm) without pre-crushing
- Pre-crushed to a small, controlled range (e.g., <500 µm) depending on material
- Liquid suspension only
- Highly agglomerated cake form
Correct Answer: Pre-crushed to a small, controlled range (e.g., <500 µm) depending on material
Q32. Which property of powder can worsen during over-micronization (excessively fine particles)?
- Increased flowability
- Increased tendency to agglomerate and reduced flowability
- Improved tableting without additives
- No change in handling properties
Correct Answer: Increased tendency to agglomerate and reduced flowability
Q33. Which maintenance practice is important for consistent operation of a fluid energy mill?
- Ignoring nozzle wear
- Regular inspection and replacement of nozzles and seals, and cleaning of classifier and cyclone
- Never cleaning the cyclone separator
- Using abrasive grinding media to clean internal parts
Correct Answer: Regular inspection and replacement of nozzles and seals, and cleaning of classifier and cyclone
Q34. Why might inert gas (e.g., nitrogen) be used instead of air in fluid energy milling?
- To increase oxygen content
- To prevent oxidation or explosive atmospheres with combustible powders
- To add moisture during milling
- To dissolve the API
Correct Answer: To prevent oxidation or explosive atmospheres with combustible powders
Q35. Which is a typical sign of overloading a fluid energy mill?
- Consistent production of finer particles
- Drop in throughput without size reduction and increased coarser fraction
- Immediate reduction in gas use
- Perfectly stable classifier behavior
Correct Answer: Drop in throughput without size reduction and increased coarser fraction
Q36. How does particle shape often change after fluid energy milling?
- Particles always become perfectly spherical
- Particles tend to become more irregular and angular due to fracturing
- Particles fuse into large rods
- Shape remains identical to feed always
Correct Answer: Particles tend to become more irregular and angular due to fracturing
Q37. Which parameter would you monitor to detect nozzle wear affecting milling performance?
- Ambient lab color
- Pressure drop across nozzle and change in particle size distribution
- Time of day
- Humidity of operator’s hands
Correct Answer: Pressure drop across nozzle and change in particle size distribution
Q38. For hygroscopic materials, what precaution is recommended before fluid energy milling?
- Increase moisture content intentionally
- Dry the material thoroughly and maintain low humidity during milling
- Add a sticky binder
- Use only warm air to increase stickiness
Correct Answer: Dry the material thoroughly and maintain low humidity during milling
Q39. Which analytical technique is commonly used to evaluate PSD after fluid energy milling?
- UV-Vis spectrophotometry only
- Laser diffraction or dynamic light scattering
- pH titration
- Thin layer chromatography
Correct Answer: Laser diffraction or dynamic light scattering
Q40. Which of the following is a correct statement about residence time in a fluid energy mill?
- Longer residence time always reduces energy consumption
- Residence time influences extent of comminution and can be affected by feed rate and circulation
- Residence time is irrelevant in jet milling
- Residence time only affects color, not size
Correct Answer: Residence time influences extent of comminution and can be affected by feed rate and circulation
Q41. Which type of pharmaceutical substances are generally NOT suitable for fluid energy milling?
- Brittle and crystalline APIs
- Highly thermolabile and sticky/fatty substances without cryogenic support
- Hard inorganic excipients
- Glass beads
Correct Answer: Highly thermolabile and sticky/fatty substances without cryogenic support
Q42. What is a typical downstream collector used in jet milling to capture fine product?
- Magnetic separator only
- Cyclone separator followed by bag filter or electrostatic precipitator
- Rotary evaporator
- Centrifugal pump
Correct Answer: Cyclone separator followed by bag filter or electrostatic precipitator
Q43. How can particle adhesion to equipment surfaces be minimized during fluid energy milling?
- Operate at high humidity
- Apply appropriate anti-static measures and use coatings or inert gas
- Use sticky binders in feed
- Increase ambient temperature drastically
Correct Answer: Apply appropriate anti-static measures and use coatings or inert gas
Q44. Which energy form is primarily responsible for particle breakage in a fluid energy mill?
- Chemical energy from reagents
- Kinetic energy of particles imparted by high-velocity gas jets
- Thermal energy only
- Electrical energy in the powder
Correct Answer: Kinetic energy of particles imparted by high-velocity gas jets
Q45. Which control strategy improves reproducibility of particle size in routine milling?
- Varying feed arbitrarily during shift
- Standardizing feed pre-conditioning, gas pressure set points and classifier settings
- Changing nozzle geometry daily
- Ignoring maintenance
Correct Answer: Standardizing feed pre-conditioning, gas pressure set points and classifier settings
Q46. What is one environmental consideration when operating fluid energy mills at industrial scale?
- They emit large volumes of solvent vapors
- Large compressed air consumption and potential particulate emissions requiring filters and energy management
- They always operate without any emissions
- They only consume renewable energy
Correct Answer: Large compressed air consumption and potential particulate emissions requiring filters and energy management
Q47. If a product shows increased amorphization after jet milling, what is a possible consequence?
- Decreased dissolution rate always
- Potential increase in apparent solubility and dissolution rate, but also possible stability issues
- Complete chemical inertness
- No change in stability
Correct Answer: Potential increase in apparent solubility and dissolution rate, but also possible stability issues
Q48. Which maintenance check helps identify air leaks that reduce milling efficiency?
- Visual inspection of product color
- Leak testing of piping, fittings and seals and monitoring compressor pressure
- Measuring tablet hardness
- Checking pH of compressed air
Correct Answer: Leak testing of piping, fittings and seals and monitoring compressor pressure
Q49. Which terminology describes the median particle size commonly reported after milling?
- D0 (zero)
- D50 (median particle diameter)
- PDI only
- RPM
Correct Answer: D50 (median particle diameter)
Q50. For regulatory documentation, which information about fluid energy milling should be included in a pharmaceutical process file?
- Only the brand name of the mill
- Process parameters (pressure, feed rate, classifier settings), PSD data, maintenance records and cleaning validation
- Only the color of the product
- Only the operator’s name
Correct Answer: Process parameters (pressure, feed rate, classifier settings), PSD data, maintenance records and cleaning validation
I am a Registered Pharmacist under the Pharmacy Act, 1948, and the founder of PharmacyFreak.com. I hold a Bachelor of Pharmacy degree from Rungta College of Pharmaceutical Science and Research. With a strong academic foundation and practical knowledge, I am committed to providing accurate, easy-to-understand content to support pharmacy students and professionals. My aim is to make complex pharmaceutical concepts accessible and useful for real-world application.
Mail- Sachin@pharmacyfreak.com
