Q1. What is the primary principle behind a multiple effect evaporator?

• Using multiple heating sources to raise temperature
• Sequential use of vapor from one effect to heat the next
• Compressing vapor to increase boiling point
• Adding vacuum to each effect separately

Correct Answer: Sequential use of vapor from one effect to heat the next

Q2. What is “steam economy” in a multiple effect evaporator?

• The ratio of feed flow to steam flow
• The amount of steam condensed per unit of evaporation
• The mass of vapor produced per unit mass of steam supplied
• The heat transfer coefficient multiplied by area

Correct Answer: The mass of vapor produced per unit mass of steam supplied

Q3. In an n-effect evaporator running at similar temperature drops per effect, the theoretical steam economy is approximately:

• n/2
• n
• 2n
• √n

Correct Answer: n

Q4. Boiling point elevation (BPE) in evaporators refers to:

• Increase in boiling point due to dissolved non-volatile solutes
• Decrease in boiling point caused by vacuum
• Temperature difference between steam and condensate
• Temperature rise in heating steam under pressure

Correct Answer: Increase in boiling point due to dissolved non-volatile solutes

Q5. Which feed arrangement minimizes thermal degradation for heat-sensitive pharmaceutical solutions?

• Forward feed
• Backward feed
• Cross feed
• Single pass feed

Correct Answer: Backward feed

Q6. Which type of evaporator is best suited for viscous or fouling-prone pharmaceutical feeds?

• Rising film evaporator
• Falling film evaporator
• Forced circulation evaporator
• Natural circulation evaporator

Correct Answer: Forced circulation evaporator

Q7. What is the main advantage of falling film evaporators in pharmaceuticals?

• High residence time for slow reactions
• Low liquid hold-up and gentle heating
• Very high circulation ratios
• Operates only under high pressure

Correct Answer: Low liquid hold-up and gentle heating

Q8. In a forward-feed multiple effect evaporator, feed enters:

• The last effect and moves to the first
• Each effect at the same point simultaneously
• The first effect and moves to successive effects of lower temperature
• Only the middle effect

Correct Answer: The first effect and moves to successive effects of lower temperature

Q9. The main purpose of a condenser in a multiple effect evaporator system is to:

• Increase feed concentration
• Condense final vapor to maintain vacuum and recover condensate
• Preheat incoming steam
• Filter solids from vapor

Correct Answer: Condense final vapor to maintain vacuum and recover condensate

Q10. Which operating parameter most directly affects evaporation rate in an effect?

• Surface roughness of tubes
• Temperature difference between heating steam and boiling liquid
• Color of the vessel
• Ambient humidity outside the plant

Correct Answer: Temperature difference between heating steam and boiling liquid

Q11. Entrainment in evaporators refers to:

• Solid particles settling at the bottom
• Liquid droplets carried away with vapor
• Condensate flowing back into feed
• Steam leaking to atmosphere

Correct Answer: Liquid droplets carried away with vapor

Q12. Which device is commonly used to reduce entrainment before vapor enters the condenser?

• Thermocompressor
• Demister or vapor separator
• Feed heater
• Plate heat exchanger

Correct Answer: Demister or vapor separator

Q13. Rising film evaporators rely on which driving force to create the film?

• Forced pumping by external pump
• Vapor-lift created by vapor generation
• Gravity exclusively
• Magnetic stirring

Correct Answer: Vapor-lift created by vapor generation

Q14. Which material is commonly used for heat transfer surfaces in pharmaceutical evaporators to resist corrosion and meet GMP?

• Plain carbon steel with no lining
• Stainless steel (SS 316)
• Cast iron
• Brass

Correct Answer: Stainless steel (SS 316)

Q15. Boiling point elevation affects multiple effect evaporators by:

• Reducing the steam economy and requiring larger heat transfer area
• Increasing vapor velocity and improving economy
• Lowering feed viscosity drastically
• Enhancing nucleate boiling uniformly

Correct Answer: Reducing the steam economy and requiring larger heat transfer area

Q16. Thermocompression in evaporators is primarily used to:

• Reduce feed volume
• Compress and reuse vapor to improve economy
• Cool the product quickly
• Separate solids from liquid

Correct Answer: Compress and reuse vapor to improve economy

Q17. For a multiple effect evaporator, “overall heat transfer coefficient (Uo)” depends on:

• Only the temperature of steam
• Fouling resistances, film coefficients, and thermal conductivity of tube wall
• Ambient air temperature
• Only the tube length

Correct Answer: Fouling resistances, film coefficients, and thermal conductivity of tube wall

Q18. Which cleaning method is preferred for internal scale removal in pharmaceutical evaporators?

• High pressure abrasive blasting
• CIP (clean-in-place) using appropriate acidic/alkaline solutions
• Manual scraping while hot
• Burning residues with open flame

Correct Answer: CIP (clean-in-place) using appropriate acidic/alkaline solutions

Q19. The term “circulation ratio” in forced circulation evaporators is defined as:

• Mass of vapor produced per unit time
• Ratio of recirculated liquid to feed in the evaporator
• Feed temperature divided by steam temperature
• Number of effects divided by heat transfer area

Correct Answer: Ratio of recirculated liquid to feed in the evaporator

Q20. Cross-flow or parallel feed arrangement is typically used when:

• Feed is highly heat-sensitive and requires minimal temperature rise
• Feed requires equal residence time in all effects and simple hardware
• Maximum steam economy is desired
• Product must be cooled rather than concentrated

Correct Answer: Feed requires equal residence time in all effects and simple hardware

Q21. Which effect in a multiple effect evaporator usually operates at the highest temperature?

• Final effect
• Middle effect
• First effect
• All effects operate at same absolute temperature

Correct Answer: First effect

Q22. A falling film evaporator is most appropriate when the product is:

• Very viscous and requires long residence time
• Heat-sensitive and requires short residence time
• Solid slurry with high particulate content
• Non-volatile gaseous mixture

Correct Answer: Heat-sensitive and requires short residence time

Q23. What is the primary disadvantage of increasing the number of effects indefinitely?

• Unlimited improvement in economy without downsides
• Higher capital cost, complexity, and diminishing returns
• Reduced product quality always
• Failure to concentrate feed at all

Correct Answer: Higher capital cost, complexity, and diminishing returns

Q24. In backward-feed arrangement, concentration increases in the direction of:

• Decreasing temperature
• Increasing temperature
• Random order
• Only within the first effect

Correct Answer: Increasing temperature

Q25. Which of the following is a common operational problem causing reduced heat transfer in evaporators?

• Excessive vacuum
• Scaling and fouling on heat transfer surfaces
• Too much demisting
• High feed humidity

Correct Answer: Scaling and fouling on heat transfer surfaces

Q26. Mechanical vapor recompression (MVR) differs from thermocompression by:

• Using steam ejectors only
• Using mechanical compressors to raise vapor pressure and temperature
• Eliminating the need for condensers
• Reducing the boiling point elevation

Correct Answer: Using mechanical compressors to raise vapor pressure and temperature

Q27. What is the effect of operating under vacuum in an evaporator?

• Increases boiling temperature of the liquid
• Lowers boiling temperature, useful for heat-sensitive materials
• Has no effect on boiling point
• Causes solids to precipitate immediately

Correct Answer: Lowers boiling temperature, useful for heat-sensitive materials

Q28. In pharmaceutical evaporations, why is minimizing residence time often important?

• To maximize color formation
• To prevent thermal degradation of active pharmaceutical ingredients
• To promote crystallization at high temperature
• To allow more scaling to form

Correct Answer: To prevent thermal degradation of active pharmaceutical ingredients

Q29. Which effect receives the steam directly from the boiler in a conventional multiple effect evaporator?

• Last effect
• Second effect
• First effect
• No effect receives boiler steam directly

Correct Answer: First effect

Q30. Heat transfer area required in an evaporator is inversely proportional to:

• Overall heat transfer coefficient and log mean temperature difference
• Mass flow of feed only
• Boiling point elevation only
• Number of operators

Correct Answer: Overall heat transfer coefficient and log mean temperature difference

Q31. Which multiple effect feed arrangement provides the best thermal efficiency but may increase product degradation?

• Forward feed
• Backward feed
• Cross feed
• Recirculation feed

Correct Answer: Forward feed

Q32. If feed contains volatile solvents (e.g., ethanol), what precaution is essential during evaporation?

• Increase steam pressure only
• Control temperature to avoid solvent loss and handle flammability, use condensation recovery
• Use open heating to vent vapors freely
• Avoid condensers to reduce contamination

Correct Answer: Control temperature to avoid solvent loss and handle flammability, use condensation recovery

Q33. Which parameter measures how much heat is transferred per unit area per degree temperature difference?

• Steam economy
• Overall heat transfer coefficient (U)
• Boiling point elevation
• Circulation ratio

Correct Answer: Overall heat transfer coefficient (U)

Q34. What is the main merit of multiple effect evaporators in pharmaceutical production?

• Higher capital cost but lower energy usage per unit evaporated
• Lower steam economy compared to single effect
• Unlimited scaling prevention
• They are single-use only

Correct Answer: Higher capital cost but lower energy usage per unit evaporated

Q35. Which factor is least likely to influence the choice between falling film and forced circulation evaporators?

• Viscosity of feed
• Heat sensitivity of product
• Particle loading in feed
• Color of the evaporator paint

Correct Answer: Color of the evaporator paint

Q36. In a multiple effect evaporator, vapour bleed is sometimes used to:

• Increase entrainment
• Provide vapor to a downstream dryer or crystallizer and control pressure
• Cool the first effect
• Replace condensers entirely

Correct Answer: Provide vapor to a downstream dryer or crystallizer and control pressure

Q37. Scaling in evaporators reduces performance primarily by:

• Increasing effective heat transfer coefficient
• Adding thermal resistance and reducing heat transfer rate
• Decreasing feed concentration automatically
• Enhancing nucleate boiling uniformly

Correct Answer: Adding thermal resistance and reducing heat transfer rate

Q38. What is the effect of high liquid viscosity on film-type evaporators?

• Improves film formation and heat transfer
• Causes thicker films, reduced heat transfer and may require forced circulation
• Has no effect at all
• Enhances vapor quality dramatically

Correct Answer: Causes thicker films, reduced heat transfer and may require forced circulation

Q39. The “log mean temperature difference (LMTD)” in evaporator design is used to:

• Estimate vapor velocity
• Calculate driving temperature difference for heat transfer across an effect
• Measure condenser pressure
• Determine steam purity

Correct Answer: Calculate driving temperature difference for heat transfer across an effect

Q40. Which method is commonly used to determine the number of effects required for a desired steam economy?

• Trial and error with no calculations
• Energy balance and steam economy equations considering boiling point elevations and ΔT per effect
• Counting the number of tanks available
• Using ambient temperature alone

Correct Answer: Energy balance and steam economy equations considering boiling point elevations and ΔT per effect

Q41. Which of the following is a demerit of multiple effect evaporators?

• High energy consumption per unit evaporated
• Complexity, higher initial capital cost and larger floor space
• Impossible to scale-up
• Cannot handle heat-sensitive materials

Correct Answer: Complexity, higher initial capital cost and larger floor space

Q42. When designing evaporators for sterile pharmaceutical products, which consideration is critical?

• Use of flammable materials for better economy
• Material selection (304/316 SS), sanitary design, and CIP compatibility
• Open-top vessels without seals
• Using unregulated condensers

Correct Answer: Material selection (304/316 SS), sanitary design, and CIP compatibility

Q43. Which control strategy helps maintain product concentration in continuous evaporators?

• Open-loop control without sensors
• Level control in effects and concentration monitoring with feedback to feed rate
• Random manual adjustments by operator only
• Shutting down half of the effects periodically

Correct Answer: Level control in effects and concentration monitoring with feedback to feed rate

Q44. Flash steam loss in evaporators can be minimized by:

• Increasing pressure drop in pipes
• Using condensers or vapor recompression and careful pressure control
• Removing demisters
• Reducing heat transfer area

Correct Answer: Using condensers or vapor recompression and careful pressure control

Q45. Which statement about thermocompressor (steam ejector) in evaporator systems is true?

• It uses motive steam to entrain and compress vapors but reduces overall steam quality
• It cools vapor without compression
• It increases the number of effects automatically
• It acts as a chemical additive to reduce scaling

Correct Answer: It uses motive steam to entrain and compress vapors but reduces overall steam quality

Q46. Why is preheating feed often practiced before entering the first effect?

• To cool the feed to ambient
• To reduce steam consumption and improve economy by using available heat
• To increase boiling point elevation unexpectedly
• To increase entrainment losses

Correct Answer: To reduce steam consumption and improve economy by using available heat

Q47. In heat-sensitive botanical extracts, which evaporator configuration is preferred?

• High temperature single effect only
• Multiple effect with backward or falling film design under vacuum
• Open kettle boiling
• Direct flame heating

Correct Answer: Multiple effect with backward or falling film design under vacuum

Q48. Which operational parameter should be monitored to avoid product foaming in evaporators?

• Feed pH, surfactant content, and vapor velocity; use antifoam if needed
• Only ambient light intensity
• Paint color of the vessel
• Time of day

Correct Answer: Feed pH, surfactant content, and vapor velocity; use antifoam if needed

Q49. In a pharmaceutical plant, the condensate from evaporators is often:

• Disposed without treatment regardless of content
• Recovered, tested and either reused as process water or sent to treatment depending on purity
• Ignited immediately
• Mixed with feed to increase yield

Correct Answer: Recovered, tested and either reused as process water or sent to treatment depending on purity

Q50. Which design approach helps reduce fouling and maintain high U in evaporators?

• Design for low shear and stagnant films
• Allow uncontrolled scale formation for protection
• High turbulence on heating surfaces, appropriate materials and regular CIP schedules
• Use narrow tubes with no access for cleaning

Correct Answer: High turbulence on heating surfaces, appropriate materials and regular CIP schedules

G S Sachin

I am a Registered Pharmacist under the Pharmacy Act, 1948, and the founder of PharmacyFreak.com. I hold a Bachelor of Pharmacy degree from Rungta College of Pharmaceutical Science and Research. With a strong academic foundation and practical knowledge, I am committed to providing accurate, easy-to-understand content to support pharmacy students and professionals. My aim is to make complex pharmaceutical concepts accessible and useful for real-world application.

Mail- Sachin@pharmacyfreak.com
